本文最后更新于：2021年4月17日中午

概述

Spark 提供了一种机制，可以根据工作负载动态调整用户的应用程序占用资源。这意味着，如果资源不再使用，应用程序可能会将它们返还给集群，并在之后需要的时候再发起请求。这个特性对于多个应用程序共享同一个 Spark 集群的时候特别有用。

Spark 默认是关闭该特性的，但是该特性在所有的集群模式下均可开启，包括 Standalone、YARN、Mesos、K8s 等，详情参考官网描述。

源码对应 Spark 2.4.5 版本。

源码分析

启动 ExecutorAllocationManager 需要配置 spark.dynamicAllocation.enabled 为 true，且不能为 local 模式，也可配置 spark.dynamicAllocation.testing 为 true 进行指定测试时启用，相关源码位于 SparkContext 中。

启动与运行

// Optionally scale number of executors dynamically based on workload. Exposed for testing.
val dynamicAllocationEnabled = Utils.isDynamicAllocationEnabled(_conf)
// 基于工作负载动态分配和删除 Executor 的代理
_executorAllocationManager =
  if (dynamicAllocationEnabled) {
    schedulerBackend match {
      case b: ExecutorAllocationClient =>
        Some(new ExecutorAllocationManager(
          schedulerBackend.asInstanceOf[ExecutorAllocationClient], listenerBus, _conf,
          _env.blockManager.master))
      case _ =>
        None
    }
  } else {
    None
  }
_executorAllocationManager.foreach(_.start())

在 ExecutorAllocationManager 启动方法中设置了对应的定时调度任务，并通过一个单一线程的线程池进行固定时间调度。

def start(): Unit = {
    // 向事件总线添加 ExecutorAllocationListener
    listenerBus.addToManagementQueue(listener)

    // 定时调度任务
    val scheduleTask = new Runnable() {
      override def run(): Unit = {
        try {
          schedule()
        } catch {
          case ct: ControlThrowable =>
            throw ct
          case t: Throwable =>
            logWarning(s"Uncaught exception in thread ${Thread.currentThread().getName}", t)
        }
      }
    }
    // 由只有一个线程且名为 spark-dynamic-executor-allocation 的 ScheduledThreadPoolExecutor 以默认值 100 ms 进行固定时间调度
    executor.scheduleWithFixedDelay(scheduleTask, 0, intervalMillis, TimeUnit.MILLISECONDS)
    // 请求所有的 Executor，numExecutorsTarget 为 spark.dynamicAllocation.minExecutors、spark.dynamicAllocation.initialExecutors、spark.executor.instances 的最大值，
    // localityAwareTasks 为本地性偏好的 Task 数量，hostToLocalTaskCount 是 Host 与想要在此节点上运行的 Task 数量之间的映射关系
    client.requestTotalExecutors(numExecutorsTarget, localityAwareTasks, hostToLocalTaskCount)

更新并同步目标 Executor 的数量，这里会比较实际需要的 Executor 最大数量和配置的 Executor 最大数量之间的关系，并根据情况决定合适的值。

private def updateAndSyncNumExecutorsTarget(now: Long): Int = synchronized {
    // 获得实际需要的 Executor 的最大数量
    val maxNeeded = maxNumExecutorsNeeded

    if (initializing) {
      // Do not change our target while we are still initializing,
      // Otherwise the first job may have to ramp up unnecessarily
      0
    } else if (maxNeeded < numExecutorsTarget) {
      // numExecutorsTarget 超过了实际需要的 Executor 最大数量，则减少需要的 Executor 数量
      // The target number exceeds the number we actually need, so stop adding new
      // executors and inform the cluster manager to cancel the extra pending requests
      val oldNumExecutorsTarget = numExecutorsTarget
      numExecutorsTarget = math.max(maxNeeded, minNumExecutors)
      numExecutorsToAdd = 1

      // If the new target has not changed, avoid sending a message to the cluster manager
      if (numExecutorsTarget < oldNumExecutorsTarget) {
        // We lower the target number of executors but don't actively kill any yet.  Killing is
        // controlled separately by an idle timeout.  It's still helpful to reduce the target number
        // in case an executor just happens to get lost (eg., bad hardware, or the cluster manager
        // preempts it) -- in that case, there is no point in trying to immediately  get a new
        // executor, since we wouldn't even use it yet.
        // 重新请求 numExecutorsTarget 指定的目标 Executor 数量，以此停止添加新的执行程序，并通知集群管理器取消额外的待处理
        // Executor 请求，最后返回减少的 Executor 数量
        client.requestTotalExecutors(numExecutorsTarget, localityAwareTasks, hostToLocalTaskCount)
        logDebug(s"Lowering target number of executors to $numExecutorsTarget (previously " +
          s"$oldNumExecutorsTarget) because not all requested executors are actually needed")
      }
      numExecutorsTarget - oldNumExecutorsTarget
    } else if (addTime != NOT_SET && now >= addTime) {
      // 如果实际需要的 Executor 最大数量小于 numExecutorsTarget，且当前时间大于上次添加 Executor 的时间，则先通知集群管理器添加新的 Executor，
      // 再更新添加 Executor 的时间，最后返回添加的 Executor 数量
      val delta = addExecutors(maxNeeded)
      logDebug(s"Starting timer to add more executors (to " +
        s"expire in $sustainedSchedulerBacklogTimeoutS seconds)")
      addTime = now + (sustainedSchedulerBacklogTimeoutS * 1000)
      delta
    } else {
      0
    }
  }
